HPE S0F35A

Aruba Instant On 1960 Switch Series



In today’s digital-first environment, small businesses face many challenges to stay afloat and competitive. With tight budgets and limited technical expertise, they’re struggling to keep up with the explosion of devices and bandwidthheavy applications running on the network. To optimize both performance and investment, small businesses need costeffective, next-gen networking solutions.

The Aruba Instant On 1960 Switch Series is an easy-to-use and affordable wired solution for networks supporting IT, mobile and cloud applications.

Aruba Instant On 1960 Switches are advanced, smartmanaged, fixed configuration Gigabit stackable switches designed for small and growing businesses that are easy to deploy and affordable. These switches are designed to scale as business grows, making adding more employees, devices and applications simple. Aruba Instant On 1960 switches are made to handle today’s bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to improve user experience and application performance.

The Aruba Instant On 1960 Switch Series includes five switches: two (2) 24-port and two (2) 48-port models in PoE and non-PoE configurations, and a 12 port 10-Gigabit aggregation switch. The access switches each have two (2) 10GBASE-T and two (2) 10G SFP+ uplink ports for highbandwidth connectivity. The 1960 aggregation switch comes with twelve (12) 10GBase-T and four (4) SFP+ ports, providing 10G connectivity to servers, network storage devices and access switches alike. With PoE models, up to 30W PoE power delivery is available for Class 4 PoE devices like access points, surveillance cameras and VoIP phones, and up to 60W PoE power delivery is available for Class 6 PoE devices like pan-tilt zoom cameras and video-enabled IP-phones. The 24-port and 48-port PoE models come with a power budget of 370W and 600W respectively to support the latest IoT devices.

The 1960 switches provide stacking capabilities: up to (four) 4 switches (access and aggregation can be mixed and matched in a stack) can be stacked together and managed through one single management IP address, simplifying network operations. This means up to 288 ports, including 16 10G uplink ports, operate as one switch.

The 1960 switches support stacking through local and cloudmanaged stacking modes. Local stacking provides True Stacking to easily configure, manage and troubleshoot physical switches as a single entity, while cloud-managed stacking provides ease-of-setup via the Instant On mobile app.

Using either the Instant On mobile app or the cloud-based web portal, you can quickly set up, monitor and manage the 1960 switch series from anywhere at any time.



Features :

• Smart-managed layer 2+ Ethernet switch series ready to deploy in 12-, 24- and 48-port for non-PoE and PoE (supports Class 4 and Class 6 PoE) models
• Up to 600W of PoE to power APs, IP Phones, surveillance cameras, door locks and other IoT devices
• 2 dedicated 10G SFP+ fiber and 2 10GBase-T uplink ports on all access models for faster network speeds that eliminate traffic bottlenecks
• Four (4) 2.5 multi-gig auto-sensing ports on a 12-port access switch with copper and fiber uplink ports to support next generation devices
• The 12-port aggregation switch comes with 12 ports of 10GBase-T to easily add expand your network reach to other stacks modernizing your network topology
• True Stacking allows for redundancy while simplifying the configuration, management, and troubleshooting of multiple switches as a single entity
• Luggage tag for easy cloud onboarding
• Convenient mobile app and web-based GUI for set up, management and troubleshooting



Specifications :

SKU	S0F35A
Brand	Aruba
Model	(S0F35A) Switch “Aruba” Instant On 1960 8G+4(2.5G) PoE/2 SFP+
Ports	8x 10/100/1000 RJ-45 4x 1/2.5GBase-T with PoE 2x SFP+ 10GbE ports 2x RJ-45 autosensing 100/1000/10GBASE-T
Processcor and Memory	Single-Core ARM v7 Cortex-A9 @800MHz 1GB DDR3; 512MB NAND flash; Packet buffer size: 1.5 MB
Throughput	172 Mpps
Switching Capacity	116Gbs
MAC Address table size	16k enties
PoE capacbility	480W
Input Voltage	100-127VAC / 200-240VAC, 50/60Hz
Power rating	Maximum: 100-127V: 635W 200-220V: 623W Idle: 100-127V: 34W 200-220V: 40W PoE: 480W
Dimension (WxHxD)	44.3 x 4.39 x 35 cm
Weight	5.24kg
Mounting	table-top/rack/wall/under-table
